Monel 625
Description
Monel 625 (also known as Alloy 625) is a nickel-chromium-molybdenum alloy with excellent corrosion and oxidation resistance. It stays strong at high temperatures and is weldable, making it suitable for aerospace, nuclear, and high-heat applications. Its purity and stable structure also suit precision instruments and medical devices.
Application：
- Jet engine exhaust systems
- Distillation columns
- Reactor core components
- Oil and gas extraction equipment
- Seawater equipment
- Aerospace components
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Chemical Composition
| Item | C | MN | P | S | Si | Cr | Ni | Mo | Co | Ti | Al | Fe | Nb |
| Monel 625 | ≤0.1 | ≤0.5 | ≤0.015 | ≤0.015 | ≤0.5 | 20.0 -23.0 | ≥58 | 8.0 – 10.0 | ≤1 | ≤0.4 | ≤0.4 | ≤5 | 3.15 – 4.15 |
Mechanical Property
| Item | Tensile Strength,min,(Mpa) | Yield Strength, min,(Mpa) | Elongation,min,(%) |
| Monel 625 | 276 | 690 | 30 |
Related Products
Resistance (μΩ.m): 0.42 – 0.45 μΩ.m
Ultimate Strength (≥ MPa): 515 MPa
Elongation (≥ %): 35%
Resistance (μΩ.m): standard
Ultimate Strength (≥ MPa): 486
Elongation (≥ %): 35
Thickness: 0.1mm-300mm
