316 Stainless Steel Square Bar
Description
The 316 stainless steel square bar is made of 316 stainless steel, which is an austenitic stainless steel containing molybdenum, which enhances the corrosion resistance of the material and maintains its performance at low or high temperatures. The square structure gives the product higher strength and uniformity. The material is especially suitable for marine environments.
Application：
- Coastal architectural paneling
- Railings & trim
- Boat fittings
- Chemical containers
- Heat Exchangers
- Woven or welded screens for mining
- Quarrying & water filtration
- Threaded fasteners
- Springs
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Specification
| Dimension Name | Value |
|---|---|
| Height | 3-500mm |
| Length | 1-12m |
| Tolerance | ±1% |
| Alloy | 316 |
| Shape | Bar-Square |
| Surface | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
| Standard | AiSi |
Mechanical Properties
| Grade | Standard (ASTM/EN/JIS/GB) | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HB) | Modulus of Elasticity (GPa) |
|---|---|---|---|---|---|---|
| 316 | ASTM A240 316 / 1.4401 / SUS316 / 06Cr17Ni12Mo2 | 515–720 | 205–275 | 45–60 | 180–220 | 193 |
Chemical Composition
| Grade | Standard (ASTM/EN/JIS/GB) | Chromium (Cr) (%) | Nickel (Ni) (%) | Molybdenum (Mo) (%) | Other Elements (%) |
|---|---|---|---|---|---|
| 316 | ASTM A240 316 / 1.4401 / SUS316 / 06Cr17Ni12Mo2 | 16.0–18.0 | 10.0–14.0 | 2.0–3.0 | Manganese (Mn), Silicon (Si), Carbon (C), Phosphorus (P), Sulfur (S) |
