Mirror Polished Stainless Steel Sheet
Description
This product is made of stainless steel plate polished by polishing equipment with abrasive liquid on the surface of the stainless steel plate, in which iron red powder, nitric acid, and water are used as grinding media. Wool felt is additionally used for grinding. The final plate surface is clear as a mirror and is referred to as 8K plate. Its high gloss, high finish, and corrosion resistance make it widely used in building decoration, elevator decoration, industrial decoration, facility decoration, and more.
Application：
- Construction
- Home appliances
- Automobiles
- Food and Medical industries
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Specification
| Dimension Name | Value |
|---|---|
| Length | 10-12000mm or as Customized |
| Width | 1000mm, 1220mm, 1250mm, 1500mm |
| Thickness | 0.3-3mm, 3mm-150mm or as Customized |
| Surface | Mirror |
| Tolerance | ±1% |
| Alloy | 201, 304, 316, 430, etc |
| Standard | ASTM, EN, GB, JIS |
Mechanical Properties
| Grade | Standard (ASTM/EN/JIS/GB) | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HB) | Modulus of Elasticity (GPa) |
|---|---|---|---|---|---|---|
| 316 | ASTM A240 316 / 1.4401 / SUS316 / 06Cr17Ni12Mo2 | 515–720 | 205–275 | 45–60 | 180–220 | 193 |
| 304 | ASTM A240 304 / 1.4301 / SUS304 / 06Cr19Ni10 | 515–620 | 205–310 | 40–60 | 180–200 | 193 |
| 201 | ASTM A240 201 / 1.4372 / SUS201 / 12Cr17Mn6Ni5N | 520–690 | 275–345 | 45–55 | 200–230 | 193 |
| 430 | ASTM A240 430 / 1.4016 / SUS430 / 10Cr17 | 450–600 | 180–270 | 20–30 | ≤200 | 200 |
Chemical Composition
| Grade | Standard (ASTM/EN/JIS/GB) | Chromium (Cr) (%) | Nickel (Ni) (%) | Molybdenum (Mo) (%) | Other Elements (%) |
|---|---|---|---|---|---|
| 316 | ASTM A240 316 / 1.4401 / SUS316 / 06Cr17Ni12Mo2 | 16.0–18.0 | 10.0–14.0 | 2.0–3.0 | Manganese (Mn), Silicon (Si), Carbon (C), Phosphorus (P), Sulfur (S) |
| 304 | ASTM A240 304 / 1.4301 / SUS304 / 06Cr19Ni10 | 18.0–20.0 | 8.0–10.5 | — | Manganese (Mn), Silicon (Si), Carbon (C), Phosphorus (P), Sulfur (S), Nitrogen (N) |
| 201 | ASTM A240 201 / 1.4372 / SUS201 / 12Cr17Mn6Ni5N | 16.0–18.0 | 3.5–5.5 | — | Manganese (Mn), Silicon (Si), Carbon (C), Nitrogen (N), Phosphorus (P), Sulfur (S) |
| 430 | ASTM A240 430 / 1.4016 / SUS430 / 10Cr17 | 16.0–18.0 | 0.5–1.0 | — | Manganese (Mn), Silicon (Si), Carbon (C), Phosphorus (P), Sulfur (S) |
