Hastelloy Supplier in China
We are a trusted Hastelloy® C22 / C276 supplier from China, offering both wholesale and retail order support.
Discover Jianglin's Hastelloy® Product Range
Hastelloy® is a nickel-molybdenum-based corrosion-resistant high-temperature alloy, renowned for its superior resistance to corrosive chemicals and thermal degradation. It is more corrosion-resistant than stainless steel, making it ideal for aerospace and chemical processing applications.
Resistance (μΩ.m): 6.84*10^-8Ω m
Ultimate Strength (≥ MPa): 620
Elongation (≥ %): 35%-55%
Bolts length: 40 mm–400mm 4″”–42″” Customized
Finish: Zinc, Plain
Thread: unF
Want to consult
the solutions you need to use Hastelloy in your industrial projects
Product Specifications
| Grade | UNS No. | Ni (%) | Mo (%) | Cr (%) | Fe (%) | Co (%) | C (%) | Si (%) | Mn (%) | W (%) | Other Elements |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hastelloy C-22 | N06022 | Bal. | 12.5-14.5 | 20.0-22.5 | ≤2.0 | ≤2.5 | ≤0.015 | ≤0.08 | ≤0.5 | 2.5-3.5 | 0.02-0.05% V |
| Hastelloy C-276 | N10276 | Bal. | 15.0-17.0 | 14.5-16.5 | 4.0-7.0 | ≤2.5 | ≤0.01 | ≤0.08 | ≤1.0 | 3.0-4.5 | 0.02-0.05% V |
| Hastelloy X | N06002 | Bal. | 8.0-10.0 | 20.5-23.0 | 17.0-20.0 | ≤1.0 | ≤0.05 | ≤1.0 | ≤1.0 | — | 0.5-2.5% Al, 0.2-1.0% Ti |
| Hastelloy B-2 | N10665 | Bal. | 26.0-30.0 | 1.0-3.0 | ≤2.0 | ≤1.0 | ≤0.01 | ≤0.10 | ≤1.0 | — | ≤0.10% P, ≤0.03% S |
| Hastelloy G-30 | N06030 | Bal. | 4.0-6.0 | 28.0-31.5 | 13.0-17.0 | ≤5.0 | ≤0.03 | ≤0.8 | ≤1.5 | — | 1.0-2.0% Cu, 0.30-1.0% Nb |
| Grade | UNS No. | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation (%) | Hardness (HB) | Melting Point (°C) |
|---|---|---|---|---|---|---|
| Hastelloy C-22 | N06022 | ≥283 | ≥690 | ≥45 | ≤250 | 1355-1400 |
| Hastelloy C-276 | N10276 | ≥283 | ≥759 | ≥40 | ≤250 | 1325-1370 |
| Hastelloy X | N06002 | ≥310 | ≥750 | ≥30 | ≤250 | 1260-1355 |
| Hastelloy B-2 | N10665 | ≥310 | ≥690 | ≥40 | ≤240 | 1370-1410 |
| Hastelloy G-30 | N06030 | ≥365 | ≥793 | ≥40 | ≤250 | 1345-1370 |
Application industries & Products
Natural Gas
Chemical Processing
Aerospace
Quality Certification
FAQ
In the spirit of complete transparency, here are some frequently asked questions we receive about Hastelloy®:
Hastelloy® conforms to ASME, ASTM, and AMS standards.
Its maximum boiling point is around 1800°F, which is lower than other alloy metals. Therefore, it is not recommended for extremely high-temperature applications.
In addition to nickel and molybdenum, Hastelloy® may contain iron, aluminium, tungsten, carbon, titanium, chromium, and other elements. It’s one of the most complexly alloyed materials in the metal industry!
