304/316L Stainless Steel Octagonal Bar
Description
Octagonal stainless steel bars are made of 316L or 304 stainless steel through cold drawing process. The octagonal structure makes it relatively high in torsion resistance, strong in load-bearing capacity, and difficult to process. 304 octagonal bars are general-purpose octagonal bars, while 316L octagonal bars are low-carbon stainless steel bars, which are more suitable for welding and highly corrosive environments. Stainless steel octagonal bars are often used in food processing, construction, marine engineering and other fields.
Application：
- Food processing
- Construction
- Marine engineering
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Specification
| Dimension Name | Value |
|---|---|
| Across Flats | customized |
| Max Length | customized |
| Alloy | 304 or 316L |
| Material | Stainless Steel |
| Shape | Bar-Octagonal |
316L Mechanical Properties
| Property | Value |
|---|---|
| Rockwell Hardness B Scale | 95 |
| Tensile Str (MPa) min | 485 |
| Yield Str 0.2% Proof (MPa) min | 170 |
| Elong (% in 50 mm) min | 40 |
| Density g/cm³ | 8 |
316L Chemical Composition
| Element | Percentage |
|---|---|
| C | 0.03 |
| Cr | 18 max |
| Mn | 2 |
| Fe | 82 |
| Mo | 3 max |
| Ni | 14 max |
| P | 0.045 |
| S | 0.03 |
| Si | 1 |
304 Mechanical Properties
| Property | Value |
|---|---|
| Density (g/cm³) | 8 |
| Ultimate Tensile Strength (KSI) | 85 |
| Yield Tensile Strength (KSI) | 35 |
| Rockwell Hardness (B Scale) | 92 max |
| Brinell Hardness (3000 kg load) | 195 max |
| Elongation (%) in 2 in. | 55 |
| Melting Point (°F) | 2550 – 2651 |
| Shear Strength (KSI) | 56 |
| Machinability (%) | 40 |
| Electrical Conductivity (% IACS) | 2 |
304 Chemical Composition
| Element | Percentage |
|---|---|
| C | 0.08 max |
| Cr | 20 |
| Fe | 66.34 – 74 |
| Ni | 8 – 10.5 |
| Mn | 2 max |
| P | 0.045 max |
| S | 0.03 max |
| Si | 1 max |
