Duplex (1.4462) Stainless Steel
Description
Duplex 1.4462 stainless steel combines the corrosion resistance of austenitic stainless with the strength of ferritic steel, making it a versatile solution for challenging environments. With double the yield strength of standard stainless grades and strong resistance to corrosion and stress cracking, it performs well in oil and gas production, desalination, and chemical handling systems. Its good weldability also allows for efficient fabrication and on-site maintenance.
Application：
- Chemical processing
- Oil and gas industry
- Marine applications
- The pulp and paper industry
- Desalination plants
- Construction industry
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 650 – 880 MPa (94 – 128 ksi) |
| Yield Strength (0.2% Proof) | ≥ 450 MPa (65 ksi) |
| Elongation | ≥ 20% |
| Hardness (Brinell) | ≤ 270 HB |
| Elastic Modulus | 200 GPa (29 × 10^6 psi) |
| Impact Energy (KV) at 20°C | ≥ 100 J/cm² |
| Impact Energy (KV) at -40°C | ≥ 40 J/cm² |
Chemistry Composition
| Element | Percentage |
|---|---|
| Chromium (Cr) | 21.0 – 23.0% |
| Nickel (Ni) | 4.5 – 6.5% |
| Molybdenum (Mo) | 2.5 – 3.5% |
| Nitrogen (N) | 0.1 – 0.22% |
| Carbon (C) | ≤ 0.03% |
| Silicon (Si) | ≤ 1.00% |
| Manganese (Mn) | ≤ 2.00% |
| Phosphorus (P) | ≤ 0.03% |
| Sulfur (S) | ≤ 0.02% |
