Super Duplex 2507
Description
Super duplex 2507 (UNS S32750) is a robust stainless steel alloy formulated for extreme environments. Containing 25% chromium, 4% molybdenum, and 7% nickel, it offers excellent resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. Designed for high-strength applications below 316°C, it is widely used in tropical marine systems, offshore oil rigs, and chemical processing where long-lasting durability and corrosion resistance are essential.
Application：
- Offshore oil and gas exploration
- Heat exchangers in chemical processing
- Hydraulic and instrumentation applications
- Chemical process
- Petrochemical
- Seawater equipment
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 900 – 1000 MPa (130 – 145 ksi) |
| Yield Strength (0.2% Proof) | ≥ 800 MPa (116 ksi) |
| Elongation | ≥ 15% |
| Hardness (Brinell) | 320 – 350 HB |
| Hardness (Rockwell C) | ≥ 32 RC |
| Elastic Modulus | 200 GPa (29 × 10^6 psi) |
Chemistry Composition
| Element | Percentage |
|---|---|
| Chromium (Cr) | 24.0 – 26.0% |
| Nickel (Ni) | 6.0 – 8.0% |
| Molybdenum (Mo) | 3.0 – 4.5% |
| Nitrogen (N) | 0.24 – 0.35% |
| Carbon (C) | ≤ 0.030% |
| Manganese (Mn) | ≤ 1.20% |
| Silicon (Si) | ≤ 0.80% |
| Phosphorus (P) | ≤ 0.035% |
| Sulfur (S) | ≤ 0.020% |
