Inconel 925
Description
A nickel-iron-chromium alloy enhanced with molybdenum, copper, and titanium. It provides strength and resistance to various corrosion types, including pitting and stress corrosion. Ideal for marine and chemical applications, and it can be hardened through heat treatment.
Application：
- Tubing and casing
- Pumps, and valves
- Structural components
- Propeller shafts
- Trim
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Mechanical Properties
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.05 g/cm³ | 0.291 lb/in³ |
| Melting point | 1311-1366° C | 2392-2491° F |
| Tensile strength | 1210 MPa | 175000 psi |
| Yield strength | 810 MPa | 117000 psi |
| Elongation at break | 24% | 24% |
| Thermal expansion coefficient (@20-100° C/68-212° F) | 13.2 μm/m° C | 7.33 μin/in° F |
Chemical Composition
| Item | C | Mn | Fe | P | S | Si | Cu | Ni | Co | Al | Ti | Cr | Nb+Ta | Mo | B | N | W | La | V | Nb |
| Inconel 925 | ≤0.03 | ≤1.0 | balance | ≤0.03 | ≤0.03 | ≤0.5 | 1.5-3.0 | 42.0-46.0 | – | 0.15-0.5 | 1.9-2.4 | 19.5-23.5 | – | 2.5-3.5 | – | – | – | – | – | – |
