Monel K500 Material
Description
Monel K500 is a stronger version of Monel 400, thanks to added aluminum and titanium and a heat treatment process that improves hardness. It resists corrosion and wear, making it ideal for marine, oil and gas, and chemical industries. This alloy can be hot-forged, cold-bent, cut, and welded.
Application：
- Pump shafts and impellers
- High-pressure vessels
- Piping and heat exchangers
- Drill collars and instruments
- Marine environments
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Chemical Composition
| Element | Percentage (%) |
|---|---|
| Nickel (Ni) | 63.00 min |
| Copper (Cu) | 29.5 |
| Aluminum (Al) | 2.7 |
| Titanium (Ti) | 0.6 |
| Carbon (C) | 0.18 max |
| Iron (Fe) | 2.00 max |
| Manganese (Mn) | 1.50 max |
| Silicon (Si) | 0.50 max |
| Sulfur (S) | 0.010 max |
Related Products
Surface: Black, pickled, bright
Standard(s): ASTM A494-5 Monel 505 M35-D
Heat treatment: Annealing, quenching, hardening, tempering
Resistance (μΩ.m):1.15
Ultimate Strength (≥ MPa):790
Elongation (≥ %):30
Width: 650-2000 mm, or customized
