Monel K500 Material

Description

Monel K500 is a stronger version of Monel 400, thanks to added aluminum and titanium and a heat treatment process that improves hardness. It resists corrosion and wear, making it ideal for marine, oil and gas, and chemical industries. This alloy can be hot-forged, cold-bent, cut, and welded.

Application：

Pump shafts and impellers
High-pressure vessels
Piping and heat exchangers
Drill collars and instruments
Marine environments

Need a custom quote

or more information about this product? Contact our sales staff today!

Product Specification

Chemical Composition

Element	Percentage (%)
Nickel (Ni)	63.00 min
Copper (Cu)	29.5
Aluminum (Al)	2.7
Titanium (Ti)	0.6
Carbon (C)	0.18 max
Iron (Fe)	2.00 max
Manganese (Mn)	1.50 max
Silicon (Si)	0.50 max
Sulfur (S)	0.010 max
