Monel R405
Description
Monel R405 is a free-machining grade of Monel 400, with similar strength and corrosion resistance but better machinability due to added sulfur. It’s great for high-speed machining and is used to make valves, fasteners, and instrument parts. It also performs well in cold-bending applications.
Application：
- Pump shafts and impellers
- High-pressure vessels
- Piping and heat exchangers
- Drill collars and
- instruments
- Marine environments
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Mechanical Properties
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.80 g/cm³ | 0.318 lb/in³ |
| Melting point | 1338° C | 2440° F |
| Tensile Strength (annealed) | 550 MPa | 79800 psi |
| Yield strength | 240 MPa | 34800 psi |
| Elongation at break (annealed) | 40% | 40% |
| Thermal expansion co-efficient | 13.7 μm/m° C | 7.61 μin/in° F |
| Thermal conductivity | 21.8 W/mK | 151 BTU in/hr.ft².° F |
Chemical Composition
| Item | Ni | Cu | Fe | Mn | Si | C | S | Pb |
| Monel R405 | ≥63.0 | 28.0 – 34.0 | ≤2.5 | ≤1.0 | ≤0.5 | ≤0.30 | ≤0.015 | ≤0.005 |
