Incoloy 925
Description
Incoloy 925 (UNS N09925) is an age-hardenable nickel-iron-chromium alloy that includes molybdenum, copper, titanium, and aluminum. It offers strong resistance to sulfide stress cracking and stress corrosion cracking in sour gas and oil environments containing hydrogen sulfide. Commonly used in downhole and surface equipment for gas wells, Incoloy 925 also performs well in subsea applications. Its high strength and hardness improve the reliability of fasteners and the durability of components like pumps and shafts.
Application：
- Down-hole and surface gas well components
- Tubular products
- Chemical processing
- Fasteners, marine and pump shafting
- Oil and gas extraction
Need a custom quote
or more information about this product? Contact our sales staff today!
Product Specification
Mechanical Properties
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.05 g/cm³ | 0.291 lb/in³ |
| Melting point | 1343° C | 2450° F |
| Tensile strength (value at room temperature) | 1210 MPa | 175000 psi |
| Tensile strength (@ 550° C/1020° F) | 970 MPa | 141000 psi |
| Yield strength (@ strain 0.200%, value at room temperature) | 810 MPa | 117000 psi |
| Yield strength (@ strain 0.200%, temperature 550° C/1020° F) | 700 MPa | 102000 psi |
| Poisson’s ratio | 0.281 | 0.281 |
| Elongation at break (precipitation hardened) | 24% | 24% |
| Thermal expansion co-efficient (@ 20-100° C/68-212° F) | 13.2 μm/m° C | 7.33 μin/in° F |
Chemical Composition
| Item | C | Mn | Fe | P | S | Si | Cu | Ni | Al | Ti | Cr | Mo |
| Incoloy 925 | ≤0.03 | ≤1 | rest | ≤0.03 | ≤0.03 | ≤0.5 | 1.5-3 | 42-46 | 0.15-0.5 | 1.9-2.4 | 19.5-23.5 | 2.5-3.5 |
